Withdrawal and Straightening Machine for Continuous Casting Machine ( CCM ) R4m – R8m , square billet output

Straightening machine is used on various continuous casting machine to straightening and leveling billet after secondary cooling. For different size of continuous casting machine, withdrawal and straightening machine has different kinds of shape, for R3m, R4m, R5.25m and for R6m.
It is mainly used in arc continuous casting machine. when billet goes along the dummy bar, it comes into the straightening machine, the shape of billet changes from arc to straight.The machine is very important in the whole set of equipment

Specification
Caster radius: R4-14
Throwing speed: 0.5m/min
Throwing specification: square, rectangular billet
Steel quality: carbon steel

Components
motor
Reducer
Gear housing
Universal coupling
Rolling stand
Straightening roll
Bearing
Press down system

FUJIAN PUTIAN GEILI MACHINERY MANUFACTURING CO.,LTD

was founded in 1995,formerly known as Xianyou Rolling Mill Manufacturer.In 2001,merged with Xianyou Bangtou Mill Roll Manufacturer. In 2008,we focused on continuous casting and rolling production line equipment. In 2011,the company reorganized and established FUJIAN PUTIAN GEILI MACHINERY MANUFACTURING CO.,LTD ,which engaged in metallurgical equipment,mainly in steel-making,continuous casting and complete rolling production line research and development,design,manufacturing, installation and general contracting services.

Main products: all kinds of specifications continuous casting machines, rolling production line equipment and various auxiliary equipment, also the spare parts. Besides, we provide technical consultant, turnkey solution and one-stop service for steel plant of deformed rebar , wire rod , angle bar, channel beam, strip and other steel related production line. The Solution was based on the customer request, such as annual capacity from 30,000 tons to over 800,000 tons, rolling speed from 3 m/s to 90 m/s.

1)Offering proposal with best solution and reasonable price for production line as per customers' invest and capacity requirement
2)Providing turn-key service of site planning, machinery designing, manufacturing, installation and commissioning for the full
production lines to meet customers requirement.
3)Technical support. We will arrange engineers on site to install and debug the production lines until the final products are meet to customers' require
4)Perfect after-sales with long-term technical support, such as after-sales adjust the production line, develop new products or improve the equipment

Quality Control:
Quality control (QC) is a procedure or set of procedures intended to ensure that a manufactured product or performed service adheres to a defined set of quality criteria or meets the requirements of the client or customer.
Finish Product QC
Ensure all the dimension and technical process are correct
Drawing QC
Ensure all the drawing are inspected by Profesional Enginners
Shipping QC
Ensure the product pass to customer are optimum and correct quantity.

As a professional and experience manufacturer in China, we can supply designing, manufacturing, installation and commissioning of the equipment with "turn-key" service.

Please send us more information about your project, we would like to give you our proposal immediately after getting your details. Sincerely welcome you to come and visit our plant.
